Click-hook pulley with safety catch C.M.U (max.): 100 kg for rope D. 20 to 26 mm - D-Work

Ref. DK-1861000001

‹ Revenir à la catégorie

Click-hook pulley with safety catch C.M.U (max.): 100 kg for rope D. 20 to 26 mm - D-Work

View larger

*Photos non contractuelles

Partager ce produit

En savoir + sur Click-hook pulley with safety catch C.M.U (max.): 100 kg for rope D. 20 to 26 mm - D-Work

This high-quality, French-made CLIC pulley can be used to lift all types of building materials, scaffolding elements, etc. When you stop pulling on the rope, a pawl locks the sheave. Its trapezoidal groove stops the rope from slipping, and you can "blow"; pulling again unlocks the pawl and you can continue to hoist or lower your load. Note that blocking the sheave by means of a ratchet does not guarantee total blockage of the rope, which must always be held by the operator, but this system does take a great deal of pressure off the operator. This pulley has a C.M.U of 100 kg (50 kg load + 50 kg effort). In practice, the pulley is designed to lift loads that a person of average strength can do without risk of losing control, i.e. around 25 to 40kg. This CLIC pulley is designed for rope diameters of 20 to 26 mm (20/22 recommended). 360° rotating suspension hook with safety latch. Before each use, lightly oil the base of the hook so that it always rotates freely. Please read the instructions supplied before using this product.

Suitable rope: D. 20 to 26 mm.
Dimensions (with hook) W x D x H: 235 x 70 x 430 mm.
Sheave diameter: 220 mm.
Material: zinc-dichromate finish and polyamide sheave.
C.M.U weight : 100 Kg.
Use: Manual.
Operating temperature: -10°C to + 50°C.
Net weight (without rope): 3.29 kg.

Made in France.

Colours may vary slightly from those shown, depending on availability.

D-Work:

D-Work products are top-of-the-range for intensive use. This product meets current standards, all at factory prices to avoid intermediaries. Find more products under the D-Work brand.

Data sheet

Status	2
Type of product	Poulie
Material	Acier bichromaté
Content	1
Maximum load	100 kg
Country of origin	CN
Person responsible EU	PRESTA'DIAM 26 Chemin du Godard 38110 ST Didier de la Tour Email : contact@prestadiam.fr
WARNING and SAFETY	Warning and Safety Information Safety Warning: This product is intended for professional and domestic use. Please follow the instructions below to ensure safe use: Proper Use: Use this tool only in accordance with the instructions provided. Do not use this tool for unintended applications. General precautions: Always wear personal protective equipment (gloves, safety goggles, hearing protection). Make sure the work area is clean and clear. Do not use the tool near water or in damp conditions. Handling and storage: Keep the tool out of the reach of children. Store the tool in a safe, dry place when not in use. Check the condition of the tool regularly. If damaged, remove immediately from use. Risk warning: This tool may present a risk of cuts, crushing or other injuries. In the event of injury, consult a doctor immediately. Recycling and disposal: Follow local regulations for disposal of this product Person responsible in the EU for our products: PRESTA'DIAM 26 Chemin du Godard 38110 ST Didier de la Tour Email: contact@prestadiam.fr
User manual	Présentation du produit : La poulie CLIC D-Work est conçue pour le levage de matériaux lourds en toute sécurité. Son système d'encliquetage facilite l'utilisation lors de la traction. Utilité principale : Permet de lever des charges jusqu'à 100 kg sans perte de contrôle. Avantages : Fabrication française, crochet rotatif à 360°, utilisation manuelle facile. Caractéristiques principales : C.M.U : 100 kg, dimensions : 235 mm x 70 mm x 430 mm, diamètre du réa : 220 mm, poids : 3,29 kg, cordes admissibles de D. 20 à 26 mm. Instructions d'utilisation : 1. Vérifiez que la corde est de diamètre adéquat. 2. Accrochez la poulie à une structure stable. 3. Lubrifiez le crochet avant utilisation. 4. Installez la corde dans la gorge de la poulie. 5. Effectuez la traction pour commencer le levage. Précautions d’utilisation : Ne pas dépasser la capacité de charge de 100 kg. Toujours maintenir la corde en tension pour éviter tout relâchement. Ne pas utiliser par temps extrême. Entretien et nettoyage : Nettoyez régulièrement la poulie, huilez le crochet pour assurer son fonctionnement optimal.
new	D-Work Poulie CLIC avec linguet de sécurité - C.M.U 100 kg - Dimensions 235 x 70 x 430 mm - Diamètre du réa 220 mm - Corde D. 20 à 26 mm - Fabrication française
new	D-Work Poulie CLIC avec linguet de sécurité robuste - C.M.U 100 kg - Dimensions 235 x 70 x 430 mm - Diamètre du réa 220 mm - Corde D. 20 à 26 mm
new	D-Work Poulie CLIC avec linguet de sécurité - C.M.U 100 kg - Dimensions 235 x 70 x 430 mm - Diamètre du réa 220 mm
KEYWORDS	D-Work, poulie clic, linguet de sécurité, levage, fabrication française, cordage, poulie 100 kg, réa polyamide, usage manuel, outil de construction
new	✅ CORDAGE ADMISSIBLE : Convient pour cordes de diamètre 20 à 26 mm, idéal pour le levage de matériaux lourds.
new	✅ GAMME HAUT DE GAMME : Produits D-Work pour un usage intensif, fabriqués en France et répondant aux normes en vigueur.
new	✅ SYSTEME D'ENCLIQUETAGE : Permet de reprendre la charge facilement grâce au cliquet et à la gorge trapézoïdale.
new	✅ UTILISATION SÉCURISÉE : Crochet rotatif à 360° avec linguet de sécurité pour un usage en toute sécurité.
new	✅ LEGERE ET PRATIQUE : Poids net de 3,29 Kg permettant de soulever jusqu'à 100 Kg avec effort.
